Ultrafast Fiber Laser Seed

· High mode-locking and output stability
· Excellent spectral quality
· Low noise

We are available 24/7 by e-mail, whatsapp or by phone. You can also use our quick contact form to ask a question about our products.

Submit

Product Description:

Features


• High mode-locking and output stability

• Excellent spectral quality

• Low noise

• High pulse energy

• Repetition frequency: 100 kHz ~ 20 MHz

• Pulse width: <10 ps@ 20 MHz

• Adjustable SESAM point


SpecificationsPicoFemto
Central Wavelength (nm)1064.3±0.11031 nm±1 nm
Pulse Width (ps)<10~4 (Compressd<150 fs)
Spectral Bandwidth (nm)<0.5>15
Single Pulse Energy (nJ)>20@1 MHz>20
PRF (MHz)0.1-2040
Polarization Extinction Ratio (dB)>20>20
Power Stability (RMS)<0.5 %<0.5 %
Dimensions (mm)200*136*70210*140*55
