Product Description:
• High mode-locking and output stability
• Excellent spectral quality
• Low noise
• High pulse energy
• Repetition frequency: 100 kHz ~ 20 MHz
• Pulse width: <10 ps@ 20 MHz
• Adjustable SESAM point
| Specifications | Pico | Femto |
| Central Wavelength (nm) | 1064.3±0.1 | 1031 nm±1 nm |
| Pulse Width (ps) | <10 | ~4 (Compressd<150 fs) |
| Spectral Bandwidth (nm) | <0.5 | >15 |
| Single Pulse Energy (nJ) | >20@1 MHz | >20 |
| PRF (MHz) | 0.1-20 | 40 |
| Polarization Extinction Ratio (dB) | >20 | >20 |
| Power Stability (RMS) | <0.5 % | <0.5 % |
| Dimensions (mm) | 200*136*70 | 210*140*55 |
